IPC API

Installation

npm install @cutos/core

Introduce dependencies

import {CoreAPI} from '@cutos/core';

CoreAPI.getIPC

Get IPC instance object

let ipc = CoreAPI.getIPC([destAddress]);

• destAddress: Optional parameter, target IP address, used for inter-device process communication

ipc.sendTo

Send IPC information

ipc.sendTo(channel, args, callback = null);

• channel: channel name
• args: information to be sent
• callback: callback function

ipc.on

Monitor IPC

ipc.on(channel, listener);

• channel: channel name
• listener: listener function (args, respond)

Local device communication example:

Example 1 (without return value):

import {CoreAPI} from '@cutos/core';

CoreAPI.init();

let channel1 = 'channel1';

let ipc = CoreAPI.getIPC();
//Listen for IPC information
ipc.on(channel1, (args) => {
console.log('on', channel1, 'received', args);
})
//Send IPC information
ipc.sendTo(channel1, 'no callback');

• Return result example:

on channel1 received: "no callback"

Example 2 (with return value):

import {CoreAPI} from '@cutos/core';

CoreAPI.init();
let channel2 = 'channel2';
let ipc = CoreAPI.getIPC();
//Monitor IPC information
ipc.on(channel2, (args, respond) => {
    console.log('on ' + channel2 + ' received: ' + JSON.stringify(args));
    respond({sum: args.opt1 + args.opt2})
})
//Sending IPC information
ipc.sendTo(channel2, {opt1: 2, opt2: 2}, (result) => {
    console.log('on ' + channel2 + ' callback: ' + JSON.stringify(result))
});

• Return result example:

  on channel2 received: {"opt1":2,"opt2":2}
  on channel2 callback: {"sum":4}

Example of inter-device process communication:

Sender (IP: 192.168.1.136)

import {CoreAPI} from '@cutos/core';

CoreAPI.init();
let channel1 = 'channel1';
//Destination IP: 192.168.1.149
let ipc = CoreAPI.getIPC("192.168.1.149");
//Send IPC information
ipc.sendTo(channel1, 'no callback');

Receiver (IP: 192.168.1.149)

import {CoreAPI} from '@cutos/core';

CoreAPI.init();
let channel1 = 'channel1';
let ipc = CoreAPI.getIPC();
//Listen for IPC information
let ipcListener = function (args) {
console.log('on', channel1, 'received', args);
}
ipc.on(channel1, ipcListener);

• Return result example:

on channel1 received: "no callback"
